SIGLENT Technologies Introduces Next Generation RF Signal Generators

Two new models for standard and advanced applications with output frequencies up to 6 GHz and Vector Signal Generation capability.


Solon, OH, US – WEBWIRE
SIGLENTíS New SSG5000X RF Signal Generator
SIGLENTíS New SSG5000X RF Signal Generator

SIGLENT Technologies has introduced two new RF Signal Generators for a wide range of RF testing applications, including the NR-5G Band (FR1) between 3.4 and 3.7 GHz. Siglentís new Model SSG5000X Series RF Signal Generator can source analog and vector signals up to 4 GHz or 6 GHz. In the same family, the new SSG5000X-V Series Generator features internal IQ modulation with an RF Modulation Bandwidth up to 150 MHz and an arbitrary waveform playback function. A well-designed menu structure makes it easy to create complex signal types.

Both of these new RF Signal Generators feature superior performace specifications. The phase noise specification is -120 dBc (@1 GHz / 20 kHz offset), the regulated maximum output level goes up to +20 dBm (settable up to +26 dBm), and the minimum output level is -130 dBm (settable down to -140 dBm). The SSG5000X can also be upgraded with an optional OCXO-module that improves the temperature stability of the source, which is especially important for precision tests and manufacturing applications.

The SSG5000X comes standard with a 5-inch touch display. The front panel and display menu structure is easy accessible and well designed, so that it takes only minutes to learn. Like most newly introduced Siglent test instruments, the SSG5000X incorporates a web server for easy remote control over Ethernet. This unit offers all analog modulation types including Pulse-Modulation as a standard feature. Different types of Frequency or Amplitude sweeps can be set and combined. The Signal Valid and Trigger In/Out BNC-connectors on the back side enable a smooth and easy implementation into automated test systems. All units support the connection of an external USB-Power Meter in order to compensate the path loss between the RF out of the generator and the DUT.

The 4 GHz Versions SSG5040X(-V) can later be upgraded to 6 GHz by Software License Key and therefore secures your investment.
The price for these new RF Signal Generators starts at $8,809.


( Press Release Image: https://photos.webwire.com/prmedia/24389/259284/259284-1.png )
