Mitsubishi Electric to Launch Super mini DIPIPM Ver.7

DIPIPM for inverter drive systems achieves low radiation noise and low power consumption


TOKYO – WEBWIRE
Super mini DIPIPM Ver.7 series
Super mini DIPIPM Ver.7 series

1

Mitsubishi Electric Corporation (TOKYO: 6503) announced the coming launch of a new high-performance intelligent power module (IPM), the Super mini DIPIPMTM Ver.7, featuring reduced radiation noise and low power consumption for the inverter drive systems of air conditioners and other small-capacity motor drives. Sales of the Super mini DIPIPM Ver.7 will begin on October 29.

Product Features

1) Low-power, low-noise DIPIPM suitable for wide-ranging applications

  • Built-in low-noise seventh-generation insulated gate bipolar transistor (IGBT) deploys CSTBTTM structure to reduce radiation noise while still maintaining the low-power consumption level of the Super mini DIPIPM Ver.6, ideal for industrial motors and many other applications
  • Reduced-noise components on circuit board ensure low radiation noise

    2) Extra-flexible heat dissipation design

  • Module case operation temperature raised from 100 to 125 degrees Celsius and maximum junction temperature raised from 150 to 175 degrees Celsius to expand the heat-dissipation design flexibility of inverter systems

    3) Higher current rating in super mini package

  • Newly increased 40A rating achieved in a super mini package

    4) Package compatibility

  • Package and pin assignment are compatible with conventional Super mini DIPIPM series

Sales Schedule

Product: Super mini DIPIPM Ver.7 Series

Model: PSS20S93E6/F6-AG - Rating: 20A / 600V - Shipment date: October 29, 2019

Model: PSS30S93E6/F6-AG - Rating: 30A / 600V - Shipment date: October 29, 2019

Model: PSS40S93E6/F6-AG - Rating: 40A / 600V - Shipment date: October 29, 2019


( Press Release Image: https://photos.webwire.com/prmedia/7/245934/245934-1.jpg )
