Mitsubishi Electric’s New "REESA" Small, Low-cost Array Antenna Achieves High-precision Beam Scanning

Mitsubishi Electric Corporation (TOKYO: 6503) announced its development of the REESA (Rotational Element Electronically Scanned Array) antenna, a small, low-cost array antenna that achieves high-precision beam scanning by electronically rotating antenna elements individually. The REESA antenna is suitable for airport radar systems, mobile satellite communication systems and possible new applications such as microwave-based industrial heating and mounting on drones for long-distance data transmission. Commercialization of the product is targeted at 2020.

Key Features

1)Rotates antenna elements individually for precise phasing and beam scanning

-Controls phase by rotating circularly polarized antenna elements individually by motors-Realizes high-precision beam scanning by controlling phase in approx. two-degree increments-Smaller and les expensive than conventional mechanically driven parabola antennas and active electronically scanned arrays (AESAs).

2)Achieves high efficiency and low power consumption

-Uses a hollow waveguide for the antenna feed to achieve high efficiency of 85 percent in 12 GHz band
